碳化硅棚板：是以高純碳化硅與超細粉結合，經振動成型，高溫燒結而成。
Silicon Carbide Board: It is combined with high purity silicon carbide and ultra fines. Shaped by vibration, maded by high sintering.
·優點：具有良好的高溫熱傳導性和高溫承重性，適用于各種建筑陶瓷、衛生陶瓷、日用陶瓷、電瓷耐火材料和粉末冶金燒結爐中使用。
·Advantage:
It has good heat conductivity and bearing ability under high temperature.It is suitable to be used in structural ceramics, sanitary ceramics, domestic ceramics, electrotechnical porcelain refractory material, sinter powder metal industry.
·常用規格：
Dimension in common usage (mm):
600*500 600*450 500*500 500*450 500*370 500*340 500*480 480*480 450*450 450*420 450*400 400*400 400*350 350*350 360*360 340*340 330*330 320*320 310*310 295*295
注：厚度可按客戶要求生產
Note :The thickness can be produced by customers’ require
·碳化硅棚板理化指標
|
化學成分
|
指標
|
物理性能
|
指標
|
|
SiC
|
90%
|
導熱率（1000℃）千卡/小時
|
9.1-11
|
|
SiO2
|
7%
|
體積密度（g/cm3)
|
2.55
|
|
Fe2O3
|
0.5%
|
顯氣孔率(%)
|
10
|
|
|
|
常溫抗折強度Kg/cm2
|
>100
|
|
|
|
荷重軟化溫度(℃)
|
1650
|
|
使用范圍
|
適用于1400℃以下窯爐
|
||
·Silicon Carbide Board Technique Index:
|
Chemical Composition
|
Index
|
Physical Property
|
Index
|
|
SiC
|
90%
|
thermal coefficient（1000℃）kilocalories per hour
|
9.1-11
|
|
SiO2
|
7%
|
volume concentration（g/cm3)
|
2.55
|
|
Fe2O3
|
0.5%
|
apparent porosity(%)
|
10
|
|
|
|
normal temperature antiflex cracking Kg/cm2
|
>100
|
|
|
|
refractoriness under load(℃)
|
1650
|
|
Serviceable Range
|
used in kiln stove under 1400℃
|
||
